A hydraulic AC servo system is a type of control system that utilizes hydraulic fluid to transmit power and control the motion of mechanical components offering high performance, accuracy, and reliability. In this guide, we’ll delve into the workings of hydraulic servo systems, exploring their components, functioning principles, applications, and advantages.

hydraulic ac servo system

Working Principle for Servo System:

  • Hydraulic servo drive systems operate based on the principle of closed-loop control, where feedback from sensors is used to adjust the system’s output to match the desired set point.
  • When a command signal is received, the Injection machine controller compares it with the feedback from sensors to determine the error (the difference between desired and actual position).
  • The Injection machine controller then adjusts the control valves to regulate the flow of hydraulic fluid, driving the actuator to minimize the error and maintain accurate positioning.

Applications of Hydraulic Servo Systems:

  • CNC Machining: Hydraulic servo motor are widely used in computer numerical control (CNC) machines for precise positioning of cutting tools and work pieces.
  • Robotics: Hydraulic servos drive enable precise and smooth movement in industrial robots, enhancing their performance in tasks such as assembly, welding, and material handling.
  • Aerospace: Hydraulic servo systems are employed in aircraft control surfaces, landing gear, and other critical components where precise control is essential for flight safety.
  • Automotive: These systems are utilized in automotive manufacturing processes for tasks like stamping, welding, and painting, ensuring high precision and productivity.

Advantages of Hydraulic AC Servo Systems :

  • High Precision: Hydraulic servo motor systems offer exceptional accuracy and repeatability, making them ideal for applications requiring precise motion control.
  • High Power Density: Hydraulic systems can deliver high forces and torques in compact designs, making them suitable for applications with demanding power requirements.
  • Durability and Reliability: Hydraulic components are known for their robustness and ability to withstand harsh operating conditions, resulting in reliable performance over time.
  • Flexibility: Hydraulic servo systems can be tailored to suit various applications by adjusting parameters such as pressure, flow rate, and control algorithms.
